HDD Dupe Box Duplicator

Description

The Vinpower Digital standalone HDD Dupe Box hard drive duplicator is the perfect solution for those that need to make larger scale back-ups or residual clones of the master hard drive (HDD) content. Available in configurations of 11 and 15 targets, which support reading and writing speeds up to a blazing fast 150MB/sec, allows the user to make quick and reliable clones of nearly any HDD using virtually any OS platforms, such as Unix, Linux, Windows, or Macintosh.

The HDD Dupe Box supports FAT16/32, extFAT, NTFS, and ext2/3/4 file systems and fits both the 2.5” or 3.5” SSD or HHD models to ensure the greatest compatibility and flexibility. Additionally, The HDD Dupe Box performs the reliable Quick Erase and/or Full Erase option, but if can also erase the HDD up to the high government DoD 5220 standards which ensure there was no trace of the content left behind.

Hardware Features:
  1. Open design for easy HDD connection
  2. Supports both 2.5” and 3.5” HDD and SSD
  3. Support of all SATA Interface, 1.5Gbps, 3.0Gbps, 6.0Gbps
  4. Industry Leading 150MB/s (9GB/min) Simultaneous Actual Transfer Speed
  5. Additional LED for HDD Power and HDD Activity, Fan Activity
  6. Supports HDD sizes 3TB +: The HDD Dupe Box can accurately copy very high capacity HDD’s, including 3TB and larger, for long term archival storage or large capacity data files.

Software Features:
  1. Standalone Operation, No PC is required
  2. Simultaneous and Independent HDD operation
  3. DoD Certified HDD Erase Support
  4. Extensive Smart File system Support - Ext2, Ext3, Ext4, NTFS, exFAT, FAT16, FAT32, HFS+
  5. Auto Partition Layout Support
  6. Operation Progress Display during Duplication
  7. Read/Write Error Skip Support
  8. Account Management Support
  9. Future functions upgradeable through Firmware Update

Model
HDD Dupe Box Hard Drive Duplicator
Operating Type
Stand-alone
Target
11, 15
Buffer Memory
256MB DDR2
HDD Interface
SATA I & II (1.5G & 3.0G), SATA III (6.0G) Compatible
HDD Form Factor
3.5" and 2.5"
CF Support
Optional (with CF Interface Module Addon)
HDD Hot Swap
Yes
Smart Copy
Yes
File System Supported
File System Supported: FAT16/32, exFAT, NTFS, ext2/3/4, HFS+
Maximum Read Speed
150MB/Sec*(9GB/min)
Maximum Write Speed
120MB/Sec*(7.2GB/min)
Max HDD Capacity
9999TB
Account Management
32 users (Standard License) or 64 users (Premium License)
Auto Counter
Yes
Language Support
English, Spanish, French, German, Italian, Japanese, and more(Chinese and Arabic can be ordered on request)
Display
20 x 2 Blue LCD
Color
Black
Firmware Upgradeable
Yes
Power Supply
Input : 90 ~ 240 V, Up to 500 WATT max
Operating Humidity
20% ~ 80%
Temperature Extremes
40°C (104°F) / 5°C (41°F)
Regulations
FCC/CE, ROHS
Manufacture
Vinpower Digital


Important Notice
  • *The actual reading/writing speed may vary depends on actual HDD device.

Target MPN
Actual Size Single Packing Double Packing
11 HDDDupeBox-11T-BK Size:
W 15.7" x D 16.5" x H 15.7"
(40 x 42 x 40 cm)

Weight:
28.1lbs (12.74 kg)
Size:
W 20.9" x D 20.9" x H 20.5"
(53 x 53 x 52 cm)

Weight:
35 lbs (15.86 kg)
Size:
W 23.6" x D 23.6" x H 23.6"
(60 x 60 x 60 cm)

Weight:
41.2 lbs (18.67 kg)
15 HDDDupeBox-15T-BK Size:
W 16.5" x D 20.3" x H 15.7"
(42 x 51.5 x 40 cm)

Weight:
34.1 lbs (15.47 kg)
Size:
W 20.9" x D 25.2" x H 20.5"
(53 x 64 x 52 cm)

Weight:
41.6 lbs (18.89 kg)
Size:
W 23.6" x D 27.6" x H 23.6"
(60 x 70 x 60 cm)

Weight:
48.5 lbs (22.01 kg)
